NU09-0.25V
NU Homogeneous U-Cup, 1/4 X 7/16 X 3/32
Part #:
NU09-0.25V
Min. Order Qty: 1
Brand: HPSI
HPSI
NU style u-cups are precision molded from 80A Buna-N and 90A Fluorocarbon homogenous rubber. Popularly termed "Huva Cup," they are beveled on the inside and outside lips and include sizes called out by Army-Navy specifications, as well as narrow cross-section sizes found in J.I.C. cylinders.
| Cross Section | : | 3/32 in |
| Height | : | 3/32 in |
| Inside Diameter | : | 1/4 in |
| Material | : | 90A Fluorocarbon |
| Outside Diameter | : | 7/16 in |
| Part Number | : | (Prefix)(C/S)-(ID) |
| Pressure Range | : | 0 TO 2,000 PSI |
| Temperature Range | : | -20° to 400°F |
- NU style
- Air cups
- Symmetrical U-seal
- 90A Fluorocarbon
